Suction module for isolation rooms
The suction module for isolation rooms prevents the spread of infectious diseases to neighboring rooms and the surrounding area by creating...
Related productsGeneral
The suction module for isolation rooms is a device that prevents the contamination of neighboring rooms and thus the spread of infectious diseases within the building and into the environment by creating a vacuum in the contaminated room. Due to the simple installation and use, the module is also suitable for quickly converting existing rooms into isolation rooms.
The device is manufactured in accordance with EU Directive 2006/42 / EC, the harmonized standards ISO 14644-1: 2015 and the GMP guidelines. The suitability of the device operation is confirmed by the validation procedure after installation.
Advantages
- High effectiveness
- Easy installation
- Simple to use
- Safe possibility of changing the filter
- Quiet operation
Working principle
The suction module for isolation rooms captures the air from the room in which it is installed, filters it and releases it to the environment outside the room. The taken air from the room is filtered by a double HEPA filter H14, which drastically reduces the number of possible contaminants and harmful particles in the extracted air. The combination of vacuum and effective suction air filtration ensures that viruses and bacteria do not spread outside the isolation room.
Use
The suction module can be easily installed in the prepared wall opening in the isolation room. Due to the efficient design of the outer housing, existing openings (windows or doors) can also be used as the installation location, so that installation in existing facilities is possible with small changes and low installation costs.
The suction module is easy to operate and is done by using the on / off switch on the device. The device is autonomous and only needs to be connected to the network for its operation.
The suction module enables the safe exchange of filters, which is carried out in the isolation room (contaminated room), so that the environment is protected against the spread of viruses and bacteria even when the filter is changed.
Specifications
Type |
OFM-N-H14-150-N |
Dimension (H x W x D) [mm] |
530x530x600 |
Weight [kg] |
50 |
Electrical connection [V/Hz/kW] |
230/50/0,2 |
Noise level [dB] |
70 |
Max. air flow [m^3/h] |
300 |
Air filtration |
YES |
Air filtration level |
Doubble HEPA filter H14 |
